Feature
-
Electrical version,much more durable compared with pneumatic version.
-
Greater processing range of AWG32-AWG11.
Wire Stripping Machine (Electrical) RSM-WS-50
- Cable Size:0.03²– 4.0mm² / AWG32-AWG11
- Max. O.D.:4.2 mm
Specification
| Model | RSE-WS-50 |
| Cable Size | 0.03²– 4.0mm² / AWG32-AWG11 |
| Max. O.D. | 4.2 mm |
| Stripping Length Tolerance | Full Strip：0.5 mm ; Half Strip：6mm |
| Cutting Depth Accuracy | 0.01 mm |
| Max. Stripping length | 20 mm |
| Voltage | AC110V / 220V |
| Cycle Time | Around 0.5 s |
| Dimension | 380 x 85 x 188 mm |
| Weight | N.W. 4.5 kg, G.W.5 .5kg |
Promotion Video
RSM-WS-50.Mp4
Product PDF
PDF Specification Download
